Click here to view our library of installation videos.
Wire - 180M (590ft)
Pegs - 250 pegs
WR150 - Landroid L
Wire - 250M (820ft.)
Pegs - 270 pegs
Included with both -
- (9) spare cutting blades and screws (blades already assembled on the unit)
- (2) waterproof wire connectors
- (8) lawn screws to secure the charging base
- (1) 20V 4Ah battery
- (1) Charging base station
Additional tools needed– you will need a hammer or mallet to secure the pegs, scissors or wire strippers to strip boundary wire before inserting into charging base, and a level. A medium duty extension cord rated for outdoor use could be necessary if you do not have a power outlet within 32 feet of the location where you will be placing your charging base.
- Keep its body and underside clean by removing built up grass and debris. Remember blades are sharp. Always remove battery before performing any maintenance.
- Periodically remove grass clippings and debris build-up from contact pins & charge strips.
- Rotate or change blades once every 4 months or as needed. Refer to your owner’s manual for instruction.
- Replace the battery as needed.
- We recommend storing your Landroid in a shed or garage during the winter.
The app will also auto-update firmware, so that your Landroid is always running on the latest version. Auto-updates can be turned off if desired, and manually updated through the app when available.
The location of the port will differ depending on the model of your Landroid, refer to your quick start guide for more information. The SIM activation can take roughly 30 minutes but can take longer than that.
|Upside Down! And Mower Lifted||Landroid overturned or lifted.|
|Blade Motor fault!||Blade disc is being prevented from rotating by object or overloaded with grass.|
|Battery temperature out of range! Please wait.||Battery is over the operating temperature allow battery to cool, consider moving the charging base to shady area or garage for Landroid to keep the Landroid protected from the elements.|
|Wire Missing!||Press start to reset - Landroid can’t find signal from the wire. Wire may not be making good connection or could mean a break in the wire.|
|Mower Locked!||If Landroid does not receive signal from your router. For 3 days it will lock as a security measure. This may happen if router loses power.|
Your Find My Landroid has kept your lawnmower connected and safe for the last year. Renew your SIM card service and keep it active for another year by clicking here: https://sim.worx.com/
AIA INTELLIGENT NAVIGATION
FIND MY LANDROID MODULE
RADIO LINK MODULE
OFF LIMITS DIGITAL FENCING
ANTI COLLISION SYSTEM
INSTALLING ACS - LANDROID M
INSTALLING FIND MY LANDROID - LANDROID M
INSTALLING OFF LIMITS - LANDROID M
INSTALLING RADIO LINK - LANDROID M
INSTALLING ACS - LANDROID L
INSTALLING FIND MY LANDROID - LANDROID L
INSTALLING OFF LIMITS - LANDROID L
INSTALLING RADIO LINK - LANDROID L
How to update software for Landroid M and L:
These instructions cover WR140, WR143, WR150, WR153.
Log in to the Account panelwith your credentials
If you haven’t registered your mower for the warranty extension, the system will ask you to do it first.
After that, select your mower from the list, and download the latest available firmware by clicking on the download button.
Copy the file as it is (no need to unzip it) to an empty and formatted FAT32 USB stick. Older ones (2/4/8GB) are preferred.
Turn off your Landroid.
Go to the rear of the Landroid to access the USB port. (See manual to locate it.)
Insert the USB in the port, and then power the unit ON.*
Follow the instructions on the display.
*Note:Make sure your Landroid is within the boundary wire when restarting. If Landroid is not inside the boundary wire, the message “Outside working area Press START to reset” will be displayed.
Need some reading material? Download Landroid’s manuals.
For more detailed and comprehensive information about your Landroid and its functionality, installation or programming, download the most current versions of the Owner’s Manual, Safety Rules and the Get Started Guide.
Click to Download PDFs for WR140, WR143, WR150, and WR153.
Still didn’t find the answers you needed? We are just one phone call away.
We get it, sometimes you need to hear a reassuring voice that puts your concerns to rest. If the information on this page hadn’t adequately addressed your issue, feel free to call our Landroid specialist at 1-800-727-6260for the help you need.
